Medium: Ground water
Sensors/Parameters: pH, TDS. Free residual Chlorine, Flow meter, Pressure. Can be extended to Nitrate, Fluoride, Hardness, Turbidity, Ammonium, Chloride, Dissolved Oxygen and more
Sensor interface: RS 485, Pulse, 4-20 mA
Sensor mounting options: Low pressure flow cell with ¾”and ½“ threaded connectors
Connectivity: 4G GSM
Data frequency: >10 min depending on the number of parameters being monitored
Data transfer protocol: HTTP
Display: LCD/LED
Dashboard: Web based
Flow meter options: 15 mm – 300 mm (Mechanical, Electromagnetic, Ultrasonic)
Calibration/cycle: Factory calibrated/ 3 months
Unit supply voltage: 24 V
Power supply: Works with 230 Volt 6 Amp
Battery backup with an option for solar cells
Dimensions and weight: 2 ft x 4 ft x 1.5 ft (l x h x d), weight 40 – 50 kg
